The High-Precision Inertial Navigation System (INS) is a compact, reliable, and versatile navigation solution designed for aerospace, unmanned vehicles, and advanced industrial applications. Featuring both pure inertial and GNSS-integrated modes, it delivers accurate positioning, orientation, and velocity data even in challenging environments where GNSS signals are unreliable.
Key features include fast initial alignment, precise heading, attitude, and velocity measurements, robust environmental adaptability, and user-friendly interfaces for seamless integration. Its aluminum alloy housing ensures efficient heat dissipation, and the modular design allows for easy installation with standardized connectors.
Ideal for composite wing aircraft, target drones, UAVs, and precision-guided systems, this INS is built for high-accuracy navigation and reliable operation under extreme conditions.
Fast Alignment: Complete initial alignment in 5 minutes.
High Accuracy:
Position: 6 nm / 1 h (pure inertial)
Heading: 0.1°/h (pure inertial hold)
Attitude: 0.05° (pure inertial hold)
Velocity: 0.2 m/s (INS/GNSS integrated)
Flexible Operation Modes: Pure inertial, GNSS-assisted, or fully integrated navigation.
Environmental Adaptability:
Operating temperature: -55°C to 70°C, storage: -55°C to 85°C
Shock: 20 g, 11 ms, vibration: 6.06 g, 20–2000 Hz
Waterproof: IP55
Compact & Lightweight: Volume 98 × 96 × 89.5 mm, weight ≤1.3 kg (general model)
User Interfaces: RS422 ports, 100 Mbps Ethernet, 24 VDC power supply
High-Rate Data Output: Up to 200 Hz navigation data for real-time applications
Durable Construction: Aluminum alloy housing with recommended aluminum base for uniform heat dissipation
| Category | Parameter | Specification |
|---|---|---|
| Performance | Alignment Time | 5 min |
| Position Accuracy (RMS) | 6 nm / 1 h (pure inertial) Better than GNSS (INS/GNSS integrated) | |
| Heading Accuracy (RMS) | Initial: 0.4° × sec(L) Pure Inertial Hold: 0.1°/h INS/GNSS Integrated: 0.2° | |
| Attitude Accuracy (RMS) | Pure Inertial Hold: 0.05° INS/GNSS Integrated: 0.03° | |
| Velocity Accuracy (RMS) | INS/GNSS Integrated: 0.2 m/s | |
| Mobility & Environmental | Angular Rate Dynamic Range | 400 °/s |
| Acceleration Dynamic Range | ±20 g | |
| Heading / Roll / Pitch Range | 0–360° / ±180° / ±90° | |
| Operating Temperature / Storage | -55°C to 70°C / -55°C to 85°C | |
| Operating Altitude | 0–20,000 m | |
| Vibration | 6.06 g, 20–2000 Hz | |
| Shock | 20 g, 11 ms, half-sine | |
| Waterproof Rating | IP55 | |
| Physical | Dimensions (L × W × H) | 98 × 96 × 89.5 mm (general) 98 × 96 × 99.5 mm (integrated) |
| Weight | ≤1.3 kg (general) ≤1.5 kg (integrated) | |
| Interfaces | Connector | 1 × J30JM-25ZKP43 (Power, RS422, Ethernet) |
| Power Supply | 24 VDC (18–36 V), ≤10 W | |
| Data Output Frequency | 200 Hz | |
| Installation | Mounting | 4 × M4 screws, 4 × Φ4.3 mm holes; bottom-mounted recommended; base flatness <0.05 mm |
| Cable Clearance | Tail-out 7.5 mm, recommended 40 mm space for rear cable | |
| Data Output | Navigation Data | High-rate INS & GNSS navigation data (position, velocity, attitude, heading) with time-stamped messages, RS422 & Ethernet output |
|
|
